Electronic manometer PG17xx
29
10 Parameter setting
Parameter setting can be carried out via the IO-Link interface or via the operating elements on the
unit.
Parameters can be set before installation or during operation.
If you change parameters during operation, this will influence the function of the plant.
u Ensure that there will be no malfunctions in your plant.
During parameter setting the unit remains in the operating mode. It continues to monitor with the
existing parameter until the parameter setting has been completed.
Depending on the parameter setting, the parameters available in the menu may change.
10.1 Parameter setting via the unit keys
The term “device keys” refers to the touch buttons [Enter], [▲] and [▼].
The touch button [Enter] is indicated by the [●] icon below.
The sensor fields of these optical keys are operated simply by touching the viewing glass. The
touch button must be completely covered to be activated. Slow covering (e.g. liquid flows over
the display) does not activate the touch button.
CAUTION
If the medium temperature is above 50 °C (122 °F), parts of the housing can increase in
temperature to over 65 °C (149 °F).
w Risk of burns
u Do not touch the device with your hands.
u If necessary, use a blunt object to make settings on the device.
Parameter setting process in general:
Intention Action
Change from the process value display to the main menu [●]
Change to the submenu Use [▼] to navigate to the submenu,
e.g. [EF], then [●]
Select the required parameter [▲] or [▼]
Change to the setting mode [●]
Modify the parameter value [▲] or [▼] > 1 s
Apply the set parameter [●]
Exit parameter setting without saving [▲] + [▼]
Return to the next higher menu level
(repeat several times to reach process value display)
[▲] + [▼]
- or -
Use [▲] or [▼] to navigate to [Back],
then [●]
Return to the process value display > 30 seconds (timeout)
The device keys can be locked (Ò Lock / unlock/40).
If [C.LOC] is displayed when an attempt is made to modify a parameter value, a parameter
setting process is active via the IO-Link communication (temporary locking).
If [S.LOC] is displayed, the sensor is permanently locked via software. This locking can only be
removed with a parameter setting software.
