1. Function and features
• The pressure sensor detects the system pressure,
• shows the current system pressure on its display (indication as
from 1% to 105% of the value of the measuring range),
• and generates 2 output signals according to the set output
configuration.
Applications
Type of pressure: relative pressure
Avoid static and dynamic overpressure exceeding the given over-
load pressure.
For gaseous media the application is limited to max. 25bar.
Even if the bursting pressure is exceeded only for a short time
the unit can be destroyed (danger of injuries)!
Indication of the current system pressure as from 1% of the
value of the measuring range. Display "0" does not mean that
the system is free of pressure!
15
ENGLISH
output 1
hysteresis function / N.O. (Hno)
hysteresis function / N.C. (Hnc)
window function / N.O. (Fno)
window function / N.C. (Fnc)
output 2
analog 4 ... 20 mA
Bursting
pressure
Permissible
overl. pressure
Measuring
range
Order no.
PN3xx0/PE3xx0 0 ... 400 bar 600 bar 1000 bar
PN3xx1/PE3xx1 0 ... 250 bar 400 bar 850 bar
PN3xx2/PE3xx2 0 ... 100 bar 300 bar 650 bar
PN3xx3/PE3xx3 0 ... 25 bar 100 bar 350 bar
PN3xx4/PE3xx4 0 ... 10 bar 50 bar 150 bar
PN3xx6/PE3xx6 0 ... 2,5 bar 20 bar 50 bar
PN3xx7/PE3xx7 0 ... 1 bar 10 bar 30 bar
PN3x29/PE3x29 -1 ... 0 bar 10 bar 30 bar
