DTI801 DTI901 DTI911 DTI921
32
Command
value
EPC length
EPC 0 to 15
Memory
bank
Address
Length
Data 0to27
Block
counter
Status bit
"Cmd Start"
Command
value
Data 0to27
Block
counter
Error value
Status bit
"Cmd End"
Status bit
"Cmd Start"
Device sets
error value
(error when
receiving da-
ta)
0x06 0x02 0x55
32
0x02 0x00
12
0x00
23
0x00 0x01 1 0x06 Data 0x01 0x42 1 1
Controller
withdraws
command
value
0x00 0x00 0x00
00
0x00 0x00
00
0x00
00
0x00 0x00 0 0x06 0x00 0x01 0x42 1 1
Device car-
ries out pre-
set com-
mand
0x00 0x00 0x00
00
0x00 0x00
00
0x00
00
0x00 0x00 0 0x00 Sin-
gle
EPC
0x00 0x00 0 0
9.9 Operating mode "WRITE DATA”
In the “WRITE DATA” operating mode more than 28 bytes can be written to an ID tag with a write
operation. The data is sequentially transferred from the controller to the device.
Transferring data from the controller to the device:
u The controller sets the command value ”0x07”, the address (16bits) and the data length (16bits) in
the process data output image. To identify the ID tag, the EPC and its length are also necessary.
For the memory bank, only the value USER: “0x03” can be specified.
u The controller starts the write operation with the status bit “Cmd Start”.
w The device acknowledges the start of the write operation by setting the status bit ”Cmd Start
Acknowledge” in the process data input image.
u The controller fills the data in the process data output image (data 0 to 27) and increases the block
counter by “1”.
w The device acknowledges receipt of the data by increasing the block counter in the process
data output image by 1.
u The two previous steps are repeated until all data has been transferred.
w The device sets the status bit “Cmd End” with the last transfer.
u The write operation is terminated.
If the operation was unsuccessful, the device sets the error value and the status bit "Cmd End"
in the process image. Data transfer is interrupted.
Byte
Process data output when
starting the write operation
Process data output during
data transmission
Process data input
0 Command value=0x07 Command value=0x07 Command value=0x07
1 Status Status Status
2 ignored Data 0 0x00
3 Length of EPC Data 1 0x00
4 EPC 0 Data 2 0x00
5 EPC 1 Data 3 0x00
6 EPC 2 Data 4 0x00
7 EPC 3 Data 5 0x00
8 EPC 4 Data 6 0x00
9 EPC 5 Data 7 0x00
10 EPC 6 Data 8 0x00
