CR1203
8
2 3
1
38,1
250
M5 M5
30
140
1: 4 x M5 threaded hole for the fixing profiles of the installation kit
2: 4 x M5 threaded hole for RAM ® mount system
3: pressure compensation element
ATTENTION
The device is equipped with a pressure compensation element. Sealing or closing the
corresponding ventilation ducts with elastic materials may damage the device.
u Do not use any sealing materials in the area around the pressure compensation
elements.
4.2.3 Light sensor and status LED
The device is equipped with a light sensor. It is used to adapt the brightness of the display and the
operating elements automatically to the ambient brightness conditions.
2
1
1: Light sensor
2: Status LED
u Avoid construction measures that cover up the light sensor.
The status LED indicates the operating states of the device.
