Remote I/O module 8DO 8DI AL4322
31
9.1.11 Counter: Reading counter values
Available parameters:
Name Description Value range Access
[maincounter_value] Main counter reading 0…4294967294 ro
1
[batchcounter_value] Batch counter value 0…65534 ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure io/counter[n] (n: 5...8), the current counter values of the main and batch
counters are displayed.
9.1.12 SSC: configuring the switching signal channels
u Observe the notes on switching signal channels: Switching signal channels (Ò/14)
Available parameters:
Name Description Value range Access
[mode] Switching mode of switching chan-
nel
• Deactivated: switching channel
deactivated (default)
• Single Point: single point mode
• Latch: latch mode
• Two Point: two point mode
• Window: window mode
rw
1
[logic] Switching logic of switching channel Active High: high active (default)
Active Low: low active
rw
1
[sp1] Setpoint 1 • 0: 0 (default)
…
• 4294967295: 4294967295
rw
1
[sp2] Setpoint 2 • 0: 0 (default)
…
• 4294967295: 4294967295
rw
1
[single_point_edge] Defines whether switching channel
should react to rising or falling coun-
ter values
• Rising Counter Value: rising edge (default)
• Falling Counter Value: falling edge
rw
1
[switch_delay] Switching delay (value in ms) • 0: 0ms (default)
…
• 65535: 65535ms
rw
1
[reset_delay] Reset delay (value in ms) • 0: 0ms (default)
…
• 65535: 65535ms
rw
1
[hysteresis] Hysteresis • 0: 0 (default)
…
• 65535: 65535
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
To configure the switching signal channels:
Requirements:
