AL4322 Remote I/O module 8DO 8DI
30
Counter
mode
Pin2 function
Count direction selec-
tion
No func-
tion
counter
transition
input 2
count di-
rection
Reset
counter
Disable
counter
Reset SSC
Latch
Pin 2
PLC / IoT
Core
CTU
CTD
CTUD
CTDIR
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select menu [io] > [counter[n]] (n: 5...8).
w The menu page displays the configuration options of the counter.
u Configure the counter module.
u Optional: Configure additional counter modules.
u Write the changed values to the device.
w The counter modules are configured.
9.1.10 Counter: Controlling counter modules
Available parameters:
Name Description Value range Access
[disable] Disable main counter and batch coun-
ter
• 0: counter module is active (default)
• 1: counter module is not active
rw
1
[reset] Reset main counter, batch counter
and CT and CTb thresholds to initial
values
• 0: no action (default)
• 1: reset
rw
1
[direction]
2
Set the counting direction for the main
counter and the batch counter
• 0: up (default)
• 1: down
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
2
only effective if operating mode of counter module = CTDIR
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure [io/counter[n]] (n: 5...8), the available control signals of the counter modules are
displayed.
u Optional: Disable the counter module.
u Optional: Reset the counter module.
u Optional: Set the counting direction of the counter module.
u Write the changed parameter values to the device.
w The selected actions are executed.
