Remote I/O module 8DO 8DI AL4322
23
LED Description Colour State Description
MOD EtherNet/IP status Green/
red/ yel-
low
Flashes Self test: device in self-test during start
Green Flashes (2Hz) Standby: device is not configured
On Device operational: device functions reliably (nor-
mal operation)
Red Flashes (1Hz) Major recoverable fault: e.g. incorrect configura-
tion
On Major unrecoverable fault: e.g. module failed
7.1.2 Ethernet
LED Description Colour State Description
LNK Status of the connection - Off No Ethernet connection
Green On Ethernet connection established
ACT Status of the data transmis-
sion
- Off No data transmission
Yellow Flashes Data transmission
7.1.3 Process connections
LED Description Colour State Description
DO1 Signal level digital output
(pin 4)
- Off Digital output - pin 4: LOW
Yellow On Digital output - pin 4: HIGH
Red On Error - voltage not available (e.g. overvoltage)
DO2 Signal level digital input (pin
2)
- Off Digital output - pin 4: LOW
Yellow On Digital output - pin 4: HIGH
Red On Error - voltage not available (e.g. overvoltage)
DI1 Signal level digital input (pin
4)
- Off Digital input - pin 4: LOW
Yellow On Digital input - pin 4: HIGH
DI2 Signal level digital input (pin
2)
- Off Digital input - pin 2: LOW
Yellow On Digital input - pin 2: HIGH
7.1.4 Voltage supply
LED Description Colour State Description
US Voltage supply status - Off No supply voltage is applied or the applied supply
voltage is too low
Green On Supply voltage applied
red On Overvoltage, undervoltage, short circuit at sensor
supply
