AL4302 Remote I/O module 8DO 8DI
60
9.3.12 Use I&M data records
The unit supports the I&M data records I&M0 to I&M3 (Ò I&M data/82).
• The data record I&M0 contains ID information. The I&M0 data record is available for each module/
submodule of the device.
• In the data records I&M1...I&M3, the user can store application and device-specific information.
I&M data records can be accessed acyclically. Access to the I&M data records takes place index-
based.
Note: Read data record
u Read the data record with the function block RDREC.
Specific parameters:
• Input ID: HW_ID of the subslot (project-specific); properties of the
subslot
• Input INDEX: index of the data record
Note: Write data record
u Write the data record with the function block WRREC.
u Observe read and write permissions!
Specific parameters:
• Input ID: HW-ID of the slot (project-specific); properties of the slot
• Input INDEX: index of the data record
