AL4242 Remote I/O module 8DO 8DI
44
w The switching signal channels are configured.
9.2.3.5 Configuring the digital outputs
Available parameters:
Parameter Description Value range Access
[current_limit] Max. output current of the digital out-
put (value in mA)
• 0: 0 A
…
• 1000: 1000mA (default)
…
• 3600: 3600mA
rw
1
[output_select] Selection of control instance of digital
output
• PLC: higher-level PLC
• Counter 1 SSC Main: Counter 1
switching channel - main counter
• Counter 1 SSC Batch: Counter 1
switching channel - batch counter
• Counter 2 SSC Main: Counter 2
switching channel - main counter
• Counter 2 SSC Batch: Counter 2
switching channel - batch counter
• Counter 3 SSC Main: Counter 3
switching channel - main counter
• Counter 3 SSC Batch: Counter 3
switching channel - batch counter
• Counter 4 SSC Main: Counter 4
switching channel - main counter
• Counter 4 SSC Batch: Counter 4
switching channel - batch counter
rw
1
[output_state_com_lost] Fallback value if fieldbus connection is
lost
• State off: OFF
• State on: ON
• Keep last: keep last valid value
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] (n: 1...4).
w The menu page shows the current settings of the digital output channels on pin 2 and pin 4 of
the port.
u Set the parameters.
u Click on to save the changes.
w The digital outputs are configured.
9.2.3.6 Reading device information
Available information:
Name Description Value range Access
[productcode] Article number AL4242 ro
1
[vendor] Vendor ifm electronic ro
1
[devicefamily] Device family Ethernet modules ro
1
[serialnumber] Serial number (12 digits) e.g. 000174210161 ro
1
[hwrevision] Hardware revision E.g. AA ro
1
[swrevision] Firmware version E.g. AL4x4x_fw_md_1.4.0.142 ro
1
