AL4242 Remote I/O module 8DO 8DI
30
Name Description Value range Access
[sp1] Batch SSC - switch point 1 • 0: 0
…
• 65535: 65535 (default)
rw
1
[sp2] Batch SSC - switch point 2 • 0: 0
…
• 65534: 65534 (default)
rw
1
[single_point_edge] Batch SSC - Defines whether the
switching channel should react to
increasing or decreasing counter
values
• Rising Counter Value: rising edge (default)
• Falling Counter Value: falling edge
rw
1
[switch_delay] Batch SSC - switching delay (value
in ms)
• 0: 0ms (default)
…
• 65535: 65535 ms
rw
1
[reset_delay] Batch SSC - reset delay (value in
ms)
• 0: 0ms (default)
…
• 65535: 65535 ms
rw
1
[hysteresis] Batch SSC - hysteresis • 0: 0 (default)
…
• 65535: 65535
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
To configure the switching signal channels:
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select menu [io] > [port[n]] > [ssc] (n: 5...8).
w The menu page shows the current settings of the switching channels of the main counter (main)
and the batch counter (batch) of the port.
u Set the parameters.
u Write the changed values to the device.
w The switching signal channels are configured.
9.1.4.5 Configuring outputs
Available parameters:
Parameter Description Value range Access
[current_limit] Max. output current of the digital out-
put (value in mA)
• 0: 0 A
…
• 1000: 1000mA (default)
…
• 3600: 3600mA
rw
1
