Remote I/O module 8DO 8DI AL4203
57
• set counting direction (only for CTDIR counter operating mode)
Position of the control signals in the cyclical output data:
• Submodule: CTU
• Submodule: CTD
• Submodule: CTUD
• Submodule: CTDIR
To control the counter modules:
Requirements:
ü Device is integrated in PROFINET project.
ü The counter submodules are configured.
ü The IEC addresses of the cyclic process data are linked to variables.
u Set the control signals in the output data of the counter submodules.
w The control signals are sent to the counter submodule.
9.3.10 Using energy monitoring
The energy monitoring data is transmitted in the cyclic process data.
The measuring accuracy of the current and voltage values of the device supply US is ±10%.
When activating and configuring the submodule [Digital Output Energy Monitoring], IEC addresses are
automatically created for the following process data:
• Supply voltage US error indication
• Supply voltage UA error indication
• Present voltage value of supply voltage US
• Present current value of supply voltage US
• Present voltage value of supply voltage UA
• Present current value of supply voltage UA
• Supply voltage US error indication
• Supply voltage UA error indication - ports 1&2
• Supply voltage UA error indication - ports 3&4
• Present voltage value of supply voltage US
• Present current value of supply voltage US
• Present voltage value of supply voltage UA
• Present current value of supply voltage UA - ports 1&2
• Present current value of supply voltage UA - ports 3&4
Position of the energy monitoring data in the cyclical input data: Submodule: Digital Output Energy
Monitoring (Ò/76)
Requirements:
ü Device is integrated in PROFINET project.
ü The submodule [Digital Output Energy Monitoring] is activated and configured.
u Connect the IEC addresses of the subslots with symbols in the global variable list.
w The user can access the energy monitoring data via symbol names in the application.
