Remote I/O module 8DO 8DI AL4203
27
Available parameters:
Name Description Value range Access
[debounce_time] Debounce time (= value * 0.1ms) • 0: 0ms (default)
…
• 500: 50 ms
rw
1
[hold_time] hold time (= value * 0.1ms) • 0: 0ms (default)
…
• 60000: 6000 ms
rw
1
[hold_level] hold level • 0: hold LOW
• 1: hold HIGH (default)
rw
1
[invert] inversion • 0: do not invert (default)
• 1: invert
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
u Select menu [io] > [port[n]] > [pin2] (n: 5...8).
w The menu page shows the available filter parameters for pin 2 of the port.
u Set the parameters.
u Select menu [io] > [port[n]] > [pin4] (n: 5...8).
w The menu page shows the available filter parameters for pin 4 of the port.
u Set the parameters.
u Write the changed values to the device.
w The digital input filters have been configured.
9.1.4.2 Configuring the counter modules
u Observe the notes on counter modules: Counter (Ò/11)
If the operating mode of a counter module is changed, the current counter values will be reset
and any active events will be deleted.
Available parameters:
Name Description Value range Access
[mode] Operating mode of the counter mod-
ule
• CTU (Up-counter): up counter (default)
• CTD (Down-counter): down counter
• CTUD (Up-counter / Down-counter): up
and down counter
• CTDIR (Direction Counter): up or down
counter
rw
1
[pin2_function] Pin 2 function of the port (Observe
note!)
• N/C: no function (default)
• Counter Edge Input 2: counting pulse
(rising edge)
• Count Direction: counting direction
• Reset (Main & Batch Counter): reset
main counter and batch counter
• Disable (Main & Batch Counter): disable
main counter and batch counter
• Reset Latch: switching signal latch
rw
1
[count_direction_selection] Control instance for selecting the
counting direction (Observe note!)
• Pin 2 Count Direction: pin 2 of the port
(default)
• IoT / PLC Count Direction: IoT core or
fieldbus control
rw
1
