AL4203 Remote I/O module 8DO 8DI
26
The fieldbus interface can only be configured via the fieldbus configuration software.
9.1.3.1 Reading the interface configuration
u Observe the notes on the configuration of the PROFINET interface: Configure the PROFINET
interface (Ò/25)
Available parameters:
Name Description Value range Access
[ipaddress] IP address of the PROFINET inter-
face
e.g. 192.100.0.10
0.0.0.0 (default)
ro
1
[subnetmask] Subnet mask of the network segment e.g. 255.255.255.0
0.0.0.0 (default)
ro
1
[ipdefaultgateway] IP address of the network gateway e.g. 192.100.0.1
0.0.0.0 (default)
ro
1
[macaddress] MAC address of the Ethernet inter-
face
e.g. 00:02:01:0E:10:7F ro
1
[hostname] Name of the device in the PROFINET
network
e.g. al4x0x ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select the [fieldbussetup] > [network] menu.
w The menu page displays the current configuration of the PROFINET interface.
9.1.3.2 Reading the connection status
Available information:
Name Description Value range Access
[connectionstatus] Status of the PROFINET connection • Disconnected: Not connected
• Connected: Connected
ro
1
[fieldbusfirmware] Firmware version of the PROFINET
stack
e.g. 5.4.0.3 (PROFINET IO Device) ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select the [fieldbussetup] menu.
w The menu page displays the status of the PROFINET connection.
9.1.4 Process connections
The [io] menu provides access to the parameters of the process connections.
9.1.4.1 Configuring the input filters
u Observe the notes on input filters: Digital input filters (Ò/9)
