Remote I/O module 8DO 8DI AL4203
21
6.6 Voltage supply
The device is connected to the supply voltages US and UA via the Power IN port.
The US supply voltage supplies the device and the sensors connected to the ports X05...X08.
The supply voltage UA supplies the actuators connected to the ports X01...X04.
Port X31 is equipped with overvoltage protection (US, UA).
Port X31 is equipped with reverse polarity protection (US, UA).
The port X31 has cross polarity protection (US, UA).
CAUTION
Exceeding the maximum input current of 16A
w Risk of fire
u I
U
and I
A
of the supply voltages US and UA accordingly, taking into account the derating
behaviour of the device:
Wiring:
43
2 1
1: L+ (US)
2: L- (UA)
3: L- (US)
4: L+ (UA)
u Disconnect power.
u Use the Port to connect the device to the 24 V DC supply voltages US and UA (20...28VSELV/
PELV).
u For connection, use an L-coded M12 connector (max. protection rating: IP65 / IP66 / IP67 / IP69K).
u Tighten the cable sockets according to the torque specifications indicated by the cable vendor.
Maximum permissible tightening torque: 0.8Nm
