Remote I/O module 16 DI AL4143
37
9.2.3.3 Configuring input filters
u Observe the notes on input filters: Digital input filters (Ò/9)
Available parameters:
Name Description Value range Access
[debounce_time] Debounce time (= value * 0.1milliseconds) • 0: 0ms (default)
…
• 500: 50 ms
rw
1
[hold_time] Hold time (= value * 0.1milliseconds) • 0: 0ms (default)
…
• 60000: 6000 ms
rw
1
[hold_level] Hold level • low: hold LOW
• high: hold HIGH (default)
rw
1
[invert] Inversion • signal not inverted: do not invert
(default)
• signal inverted: invert
rw
1
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] (n: 1...8).
w The menu page shows the current settings of the digital input filters on pin 2 and pin 4 of the
port.
u Set the parameters.
u Click on to save the changes to the device.
w The filters of the digital inputs are configured.
9.2.3.4 Configuring counter modules
u Observe the notes on counter modules: Counter (Ò/11)
If the operating mode of a counter module is changed, the current counter values will be reset
and any active events will be deleted.
For the parameters [pin2_function] and [count_direction_selection] all shown parameter values can be
selected. It is not checked whether these make sense. For each counter operating mode (parameter
[mode]), the table below indicates the valid value ranges (: valid setting; : invalid setting):
[mode]
[pin2_function] [count_direction_selection]
No function
Counting
pulse
Counting di-
rection
Reset main
counter and
batch coun-
ter
Disable main
counter and
batch coun-
ter
Pin 2
IoT Core /
Fieldbus
PLC
CTU
CTD
CTUD
CTDIR
CTDIR
Available parameters:
