AL4143 Remote I/O module 16 DI
36
Name Description Value range Access
[configuration] > [byteswap] Arrangement of the bytes in a data word • big-endian: Big-endian format
• little-endian: Little-endian
format
rw
1
1
Read and write
2
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [fieldbussetup] > [configuration] submenu.
u Select the [fieldbussetup] > [network] submenu.
w The menu page shows the current settings.
u Set the parameters.
u Click on to save the changes to the device.
u If necessary, restart the device.
w The ModbusTCP interface is configured.
9.2.3.2 Setting the arrangement of the digital inputs
The arrangement of the digital input channels in Modbus registers 0, 400 and 401 is adjustable.
Available options:
• Pin-based:
Word
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n X8
pin 2
X7
pin 2
X6
pin 2
X5
pin 2
X4
pin 2
X3
pin 2
X2
pin 2
X1
pin 2
X8
pin 4
X7
pin 4
X6
pin 4
X5
pin 4
X4
pin 4
X3
pin 4
X2
pin 4
X1
pin 4
• Port-based:
Word
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n X8
pin 2
X8
pin 4
X7
pin 2
X7
pin 4
X6
pin 2
X6
pin 4
X5
pin 2
X5
pin 4
X4
pin 2
X4
pin 4
X3
pin 2
X3
pin 4
X2
pin 2
X2
pin 4
X1
pin 2
X1
pin 4
Available parameters:
Name Description Value range Access
[di_channel_mapping] Setting the arrangement of the digital in-
puts in the process data
• 0: Pin-based
• 1: Port-based
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [io] submenu.
w The menu page shows the current settings.
u Set the parameters.
u Click on to save the changes to the device.
w The arrangement of the digital input channels is configured.
