AL4143 Remote I/O module 16 DI
30
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure [io/counter[n]] (n: 1...8), the current counter values of the main and batch counters
are displayed.
9.1.5.3 Controlling counter modules
Available parameters:
Name Description Value range Access
[disable] Disable main counter and batch coun-
ter
• 0: counter module is active (default)
• 1: counter module is not active
rw
1
[reset] Reset main counter, batch counter
and CT and CTb thresholds to initial
values
• 0: no action (default)
• 1: reset
rw
1
[direction]
2
Set the counting direction for the main
counter and the batch counter
• 0: up (default)
• 1: down
rw
1
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
2
only effective if operating mode of counter module = CTDIR
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure [io/counter[n]] (n: 1...8), the available control signals of the counter modules are
displayed.
u Optional: Disable the counter module.
u Optional: Reset the counter module.
u Optional: Set the counting direction of the counter module.
u Write the changed parameter values to the device.
w The selected actions are executed.
9.1.5.4 Reading status and diagnostic information
Available information:
Parameter Description Value range Access
[temperature] Temperature of the device (value in
°C)
-30…80 ro
1
[voltage_us] Present voltage value of the device
supply US (value in mV)
0…40000 ro
1
[supervisionstatus_us] Status of the device supply US • 0: No error
• 1: Error
ro
1
[current_us] Present current value of the device
supply US (value in mA)
0…40000 ro
1
1
Read only
