Je bekijkt pagina 29 van 62
Remote I/O module 16 DI AL4143
29
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select menu [io] > [counter[n]] (n: 1...8).
w The menu page displays the configuration options of the counter.
u Configure the counter module.
u Optional: Configure additional counter modules.
u Write the changed values to the device.
w The counter modules are configured.
9.1.5 Process data
The dashboard area provides access to the device’s process data.
To display the dashboard area:
ü The parameter value editor for the device is open.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
To hide the dashboard area:
ü The dashboard area is displayed.
u Click on the vertical bar in the middle of the screen: Click on .
w The dashboard view is hidden.
9.1.5.1 Reading digital input data
Available information:
Name Description Value range Access
[digital] Signal level of the digital input chan-
nel (after filtering)
LOW: off
HIGH: on
ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w The view shows the current signal levels of the digital outputs at pin 2 and pin 4 in substructure [io/
port[n]] (n: 1...8).
The displayed signal levels are the filtered input data.
9.1.5.2 Reading counter values
Available parameters:
Name Description Value range Access
[maincounter_value] Main counter reading 0…4294967294 ro
1
[batchcounter_value] Batch counter value 0…65534 ro
1
