Remote I/O module 16 DI AL4043
47
Mapping: Counter Data and Status
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n Main Counter Value (Word 0)
n+1 Main Counter Value (Word 1)
n+2 Batch Counter Value
n+3 res. res. res. res. res. res. MC
OF
MC
UF
res. res. res. res. res. res. BC
OF
BC
UF
Legend:
• Main Counter Value Current counter value of the main counter 2WORD
/ ro
• 0x00000000: 0
…
• 0xFFFFFFFE: 4294967294
• Batch Counter Value Current counter value of the batch counter 1WORD
/ ro
• 0x0000: 0
…
• 0xFFFE: 65534
• MC OF Main Counter Overflow: Overflow event at the
main counter
1BIT /
ro
• 0x0: no event
• 0x1: Overflow event
• MC UF Main Counter Underflow: Underflow event at
the main counter
1BIT /
ro
• 0x0: no event
• 0x1: Underflow event
• BC OF Main Counter Overflow: Overflow event at the
batch counter
1BIT /
ro
• 0x0: no event
• 0x1: Overflow event
• BC UF Batch Counter Underflow: Underflow event at
the batch counter
1BIT /
ro
• 0x0: no event
• 0x1: Underflow event
