AL4043 Remote I/O module 16 DI
46
11 Appendix
11.1 ModbusTCP
11.1.1 Register
11.1.1.1 Input data (0 - 34)
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 DI
Ch15
DI
Ch14
DI
Ch14
DI
Ch13
DI
Ch12
DI
Ch11
DI
Ch10
DI
Ch09
DI
Ch08
DI
Ch07
DI
Ch06
DI
Ch05
DI
Ch04
DI
Ch03
DI
Ch02
DI
Ch01
1 MC8
OF
MC7
OF
MC6
OF
MC5
OF
MC4
OF
MC3
OF
MC2
OF
MC1
OF
MC8
UF
MC7
UF
MC6
UF
MC5
UF
MC4
UF
MC3
UF
MC2
UF
MC1
UF
2 MC8
OF
MC7
OF
MC6
OF
MC5
OF
MC4
OF
MC3
OF
MC2
OF
MC1
OF
BC8
UF
BC7
UF
BC6
UF
BC5
UF
BC4
UF
BC3
UF
BC2
UF
BC1
UF
3…6
Counter 1: Mapping: Counter Data and Status (Ò/47)
7…10
Counter 2: Mapping: Counter Data and Status (Ò/47)
11…14
Counter 3: Mapping: Counter Data and Status (Ò/47)
15…18
Counter 4: Mapping: Counter Data and Status (Ò/47)
19…22
Counter 5: Mapping: Counter Data and Status (Ò/47)
23…26
Counter 6: Mapping: Counter Data and Status (Ò/47)
27…30
Counter 7: Mapping: Counter Data and Status (Ò/47)
31…34
Counter 8: Mapping: Counter Data and Status (Ò/47)
Legend:
• DI Chx Signal level of the digital input channel Chx (x:
01...16) after filtering
1 BIT / ro • 0x0: LOW
• 0x1: HIGH
• MCx OF Main Counter x Overflow: Overflow event at the
main counter x (x: 1...8)
1BIT / ro • 0x0: no event
• 0x1: overflow event
• MCx UF Main Counter x Underflow: Underflow event at
the main counter x (x: 1...8)
1BIT / ro • 0x0: no event
• 0x1: underflow event
• BCx OF Main Counter x Overflow: Overflow event at the
batch counter x (x: 1...8)
1BIT / ro • 0x0: no event
• 0x1: overflow event
• BCx UF Batch Counter x Underflow: Underflow event at
the batch counter x (x: 1...8)
1BIT / ro • 0x0: no event
• 0x1: underflow event
