AL4043 Remote I/O module 16 DI
38
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 1...8).
w The menu page shows current counter values of the counter module.
9.2.4.3 Controlling counter modules
Available control signals:
Name Description Values Access
[reset] Reset counter module (reset counter
and threshold values to default values)
• inactive: no action (default)
• active: reset
rw
1
[disable] Disable counter module • inactive: enable counter (default)
• active: disable counter
rw
1
[direction]
2
Set counting direction for main counter
and batch counter
• up: up (default)
• down: down
rw
1
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
2
only effective if operating mode of counter module = CTDIR
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 1...8).
w The menu page shows the available services.
u Set the control signals.
u Click on to send the control signals to the device.
w The control signals are executed.
9.2.4.4 Reading status and diagnostic information
Available information:
Name Description Value range Access
[temperature] Device temperature (value in °C) E.g. 52: 52°C ro
1
[voltage_us] Present voltage value of device supply
US (value in mV)
E.g. 25236: 25236mV ro
1
[current_us] Present current value of device supply
US (value in mA)
E.g. 82: 82mA ro
1
[supervisionstatus_us] Status of device supply US • OK: no error
• Fault: error
ro
1
[uptime] Time since the last start of the device
(value in minutes)
• 0x0000: 0 min
…
• 0xFFFF: 65535 min
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [processdatamaster] submenu.
w The menu page shows status and diagnostic information.
