AL4043 Remote I/O module 16 DI
22
9.1.3 Fieldbus interface
The [fieldbus] menu provides access to the configuration of the fieldbus interface.
The fieldbus interface can only be configured via the fieldbus configuration software.
9.1.3.1 Configuring the ModbusTCP interface
The ModbusTCP interface of the device must be configured for communication with the ModbusTCP
network.
Available parameters:
Name Description Value range Access
[dhcp] Status of the DHCP client of the de-
vice
• Static IP: IP parameters are set by the
user
• DHCP: IP parameters are set by a
DHCP server in the network (default)
• BOOTP: IP parameters are set via the
Bootstrap Protocol
rw
1
[ipaddress] IP address of the ModbusTCP inter-
face
e.g. 192.100.0.10
• 192.168.1.250 (default)
rw
1
[subnetmask] Subnet mask of the network segment e.g. 255.255.255.0
• 255.255.255.0 (default)
rw
1
[ipdefaultgateway] IP address of the network gateway e.g. 192.100.0.1
• 0.0.0.0 (default)
rw
1
[macaddress] MAC address of the Ethernet inter-
face
e.g. 00:02:01:0E:10:7F ro
2
[hostname] Name of the device in the Mod-
busTCP network
e.g. al4x4x ro
2
1
Read and write
2
Read only
To configure the ModbusTCP interface:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
u Select the [fieldbussetup] > [network] menu.
w The menu page shows the current settings.
u Set IP parameters of the interface.
u Write the changed values to the device.
u Restart the device.
w The ModbusTCP interface is configured
9.1.3.2 Setting ModbusTCP-specific parameters
Changes to the [byteswap] parameters will only take effect after the device has been restarted.
Available parameters:
