Remote I/O module 16 DI AL4033
57
11.1.2.5 Configuration area (0x8000 - 0x8FFF)
Index Subindex Name Possible values
Data type /
access
0x8000 DI Channel Mapping • 0x0: pin-based (default)
• 0x1: port-based
UINT8 / rw
0x8001 Settings – DI Module Port 1
• 0x01 Invert DI – Pin 4 • 0x00: do not invert (default)
• 0x01: invert
UINT8 / rw
• 0x02 Hold Level – Pin 4 • 0x00: hold LOW level
• 0x01: hold HIGH level (default)
UINT8 / rw
• 0x03 Debounce Time – Pin 4 (= value
* 0.1ms)
• 0x0000: 0ms (default)
…
• 0x01F4: 50 ms
UINT16 / rw
• 0x04 Hold Time – Pin 4 (= value *
0.1ms)
• 0x0000: 0ms (default)
…
• 0xEA60: 6000 ms
UINT16 / rw
• 0x05 Invert DI – Pin 2 • 0x00: do not invert (default)
• 0x01: invert
UINT8 / rw
• 0x06 Hold Level – Pin 2 • 0x00: hold LOW level
• 0x01: hold HIGH level (default)
UINT8 / rw
• 0x07 Debounce Time – Pin 2 (= value
* 0.1ms)
• 0x0000: 0ms (default)
…
• 0x01F4: 50 ms
UINT16 / rw
• 0x08 Hold Time – Pin 2 (= value *
0.1ms)
• 0x0000: 0ms (default)
…
• 0xEA60: 6000 ms
UINT16 / rw
0x8002
Settings – DI Module Port 2 (structure: Ò Index 0x8001)
0x8003
Settings – DI Module Port 3 (structure: Ò Index 0x8001)
0x8004
Settings – DI Module Port 4 (structure: Ò Index 0x8001)
0x8005
Settings – DI Module Port 5 (structure: Ò Index 0x8001)
0x8006
Settings – DI Module Port 6 (structure: Ò Index 0x8001)
0x8007
Settings – DI Module Port 7 (structure: Ò Index 0x8001)
0x8008
Settings – DI Module Port 8 (structure: Ò Index 0x8001)
0x8010 Settings – Counter Module Port 1
• 0x01 Counter mode • 0x00: CTU -up counter (default)
• 0x01: CTD -down counter
• 0x02: CTUD -up and down counter
• 0x03: CTDIR -up and down counter with
selectable counting direction
UINT8 / rw
• 0x02 Pin 2 function For CTU and CTD:
• 0x00: N/C -no function (default)
• 0x03: Reset - reset counter module
• 0x04: Disable - disable counter module
For CTUD:
• 0x01: Counter Edge Input Pin2 -counting input
For CTDIR:
• 0x02: count direction
UINT8 / rw
• 0x03 Count direction selection (CT-
DIR only)
• 0x00: pin 2 count direction (default)
• 0x01: IoT / PLC count direction
UINT8 / rw
• 0x04 Main counter threshold • 0x00000001: 1
…
• 0xFFFFFFFF: 4294967295 (default)
UINT32 / rw
