11.1.2.4 Output area (0x7000 - 0x7FFF)
Index Subindex Name Possible values
Data type /
access
0x7010 Output Module 2
• 0x01 Reset Main and Batch Counter • 0x00: no action
• 0x01: reset main counter and batch counter
UINT8 / ro
• 0x02 Disable Main and Batch Counter • 0x00: enable main and batch counter
• 0x01: disable main and batch counter
UINT8 / ro
• 0x03 Counter Direction • 0x00: up
• 0x01: down
UINT8 / ro
0x7018 Reset Counter Event Port 1
• 0x01 Reset Main Counter Event Over-
flow
• 0x00, 0x02…0xFF: no action
• 0x01: Reset
UINT8 / wo
• 0x02 Reset Main Counter Event Un-
derflow
• 0x00, 0x02…0xFF: no action
• 0x01: Reset
UINT8 / wo
• 0x03 Reset Batch Counter Event
Overflow
• 0x00, 0x02…0xFF: no action
• 0x01: Reset
UINT8 / wo
• 0x04 Reset Batch Counter Event Un-
derflow
• 0x00, 0x02…0xFF: no action
• 0x01: Reset
UINT8 / wo
• 0x05 Reset counter events • 0x00, 0x02…0xFF: no action
• 0x01: Reset
UINT8 / wo
0x7020
Output Module 2 (structure: Ò Index 0x7010)
0x7028
Reset Counter Event Port 2 (structure: Ò Index 0x7018)
0x7030
Output Module 3 (structure: Ò Index 0x7010)
0x7038
Reset Counter Event Port 3 (structure: Ò Index 0x7018)
0x7040
Output Module 4 (structure: Ò Index 0x7010)
0x7048
Reset Counter Event Port 4 (structure: Ò Index 0x7018)
0x7050
Output Module 5 (structure: Ò Index 0x7010)
0x7058
Reset Counter Event Port 5 (structure: Ò Index 0x7018)
0x7060
Output Module 6 (structure: Ò Index 0x7010)
0x7068
Reset Counter Event Port 6 (structure: Ò Index 0x7018)
0x7070
Output Module 7 (structure: Ò Index 0x7010)
0x7078
Reset Counter Event Port 7 (structure: Ò Index 0x7018)
0x7080
Output Module 8 (structure: Ò Index 0x7010)
0x7088
Reset Counter Event Port 8 (structure: Ò Index 0x7018)
