Remote I/O module 16 DI AL4033
47
Index Subindex Name Possible values
Data type /
access
0x10F3 • 0x05 Flags
Mapping: Flags (Ò/50)
UINT16 / rw
• 0x06 Diagnosis Message 01
Mapping: Diagnosis Message (Ò/51)
OCTET
STRING / ro
… … … …
• 0x32 Diagnosis Message 50
Mapping: Diagnosis Message (Ò/51)
OCTET
STRING / ro
0x10F8 -- Timestamp (value in ns) UINT64 / ro
0x1601 RxPDO Mapping of Outputs Module 2
• 0x01 1 Byte Out (0) • PDO Content: 0x7010:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7010:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7010:03 UINT32 / rw
0x1602 RxPDO Mapping of Outputs Module 3
• 0x01 1 Byte Out (0) • PDO Content: 0x7020:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7020:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7020:03 UINT32 / rw
0x1603 RxPDO Mapping of Outputs Module 4
• 0x01 1 Byte Out (0) • PDO Content: 0x7030:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7030:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7030:03 UINT32 / rw
0x1604 RxPDO Mapping of Outputs Module 5
• 0x01 1 Byte Out (0) • PDO Content: 0x7040:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7040:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7040:03 UINT32 / rw
0x1605 RxPDO Mapping of Outputs Module 6
• 0x01 1 Byte Out (0) • PDO Content: 0x7050:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7050:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7050:03 UINT32 / rw
0x1606 RxPDO Mapping of Outputs Module 7
• 0x01 1 Byte Out (0) • PDO Content: 0x7060:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7060:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7060:03 UINT32 / rw
0x1607 RxPDO Mapping of Outputs Module 8
• 0x01 1 Byte Out (0) • PDO Content: 0x7070:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7070:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7070:03 UINT32 / rw
0x1608 RxPDO Mapping of Outputs Module 9
• 0x01 1 Byte Out (0) • PDO Content: 0x7080:01 UINT32 / rw
• 0x02 1 Byte Out (1) • PDO Content: 0x7080:02 UINT32 / rw
• 0x03 1 Byte Out (2) • PDO Content: 0x7080:03 UINT32 / rw
0x1A00 TxPDO Mapping of Inputs Module 1
• 0x01 2 Bytes Out (0) • PDO Content: 0x6000:01 UINT32 / rw
0x1A01 TxPDO Mapping of Inputs Module 2
• 0x01 4 Bytes In (0) • PDO Content: 0x6010:01 UINT32 / rw
• 0x02 2 Bytes In (1) • PDO Content: 0x6010:02 UINT32 / rw
