AL4033 Remote I/O module 16 DI
46
11.1.2 Object directory
11.1.2.1 Communication area (0x1000 - 0x1FFF)
Index Subindex Name Possible values
Data type /
access
0x1000 -- Device Type • 0x184C1389: Modular Device Profile (MDP) UINT32 / ro
0x1008 -- Manufacturer Device Name "AL4033" STRING / ro
0x1009 -- Manufacturer Hardware Version E.g. "AA" STRING / ro
0x100A -- Manufacturer Software Version E.g. "1.4.0" STRING / ro
0x1018 -- Identity Object
• 0x01 Vendor ID 0x00000622: ifm electronic UINT32 / ro
• 0x02 Product Code 0x00004033 UINT32 / ro
• 0x03 Revision Number E.g. 0x00000001 UINT32 / ro
• 0x04 Serial number Device-dependent UINT32 / ro
0x10F3 Diagnosis History
• 0x01 Maximum Messages • 0x00: 0 messages
…
• 0x32: 50 messages
UINT8 / ro
• 0x02 Newest Message • 0x01: message 1
…
• 0x32: message 50
UINT8 / ro
• 0x03 Newest Acknowledged Message Override Mode:
• 0x00: Reading: When the message queue will
be overwritten, the slave shall set subindex
0x03 to 0
• 0x01…0x05: Writing: The slave shall return
SDO-Abort with codes 0x06090030 (value
range of parameter exceeded) or 0x0609003
• 0x06…0x46: Writing: Subindex 0x03 = Written
value without checking
• 0x47…0xFF: Writing: SDO-Abort with codes
0x06090030 or 0x06090031(value of
parameter written too high)
Acknowledge Mode:
• 0x00:
– Read: No messages have been
acknowledged so far
– Writing: All acknowledged messages will be
deleted
• 0x01…0x05: Writing: The slave shall return
SDO-Abort with codes 0x06090030 (value
range of parameter exceeded) or 0x06090032
• 0x06…0x37:
– Read: Subindex of latest acknowledged
diagnosis message
– Writing: Messages are acknowledged
• 0x38…0xFF: Writing: SDO-Abort with codes
0x06090030 or 0x06090031(value of
parameter written too high)
UINT8 / rw
• 0x04 New Message Available Override mode:
• 0x0: Newest message was read
• 0x1: Newest message was not read
Acknowledge mode:
• 0x0: No acknowledged message
• 0x1: Diagnosis messages are available which
can be acknowledged (subindex 0x02 <>
subindex 0x03)
BOOL / ro
