AL4033 Remote I/O module 16 DI
30
9.2 EtherCAT
9.2.1 Installing the ESI file
For mapping of the device in an EtherCAT projection software, ifm electronic provides a device
description file in ESI format (ESI - Electronic Slave Information). In the ESI file, all parameters,
process data and their valid status and diagnostic information are defined.
The ESI file is available on ifm’s website: www.ifm.com
Example:
To install the ESI file in the TwinCAT 3.1 EtherCAT projection software:
u Download the ESI file.
u Copy the file to the following subdirectory of the TwinCAT installation directory: ..
\3.1\Config\Io\EtherCAT
u Start TwinCAT.
w The device description is loaded into the device catalogue.
w TwinCAT can access data provided by the device.
9.2.2 Integrating the device into a project
The device is integrated into the automation project as an EtherCAT slave.
To integrate the device into a TwinCAT project:
Requirements:
ü The ESI file of the device is installed in TwinCAT.
ü The project contains an EtherCAT master to which the device is connected.
u In the [Solution Explorer]: Mark the EtherCAT master under the [I/O] node.
u Right-click the node of the EtherCAT master.
w The context menu appears.
u Click on [Add new item…].
w A dialogue window appears.
u Under [ifm electronic] > [ifm Remote-IO], select the device.
u Click on [OK].
w The device has been added to the project.
