AL2507 IO-Link input/output module
18
Parameter Index Subindex Value (Hz) Increments Factory setting
PWM freq X1.0...X1.3 15010 0 20 – 1000 1 100
• PID controller
The PWM-I functionality generates current by setting the corresponding duty cycle of the PWM
signal. This means that the PWM-I output supplies more current at a constant frequency the more
the duty cycle increases. The corresponding current is generated by a PID controller. The gain
factor for the proportional component of the PID controller can be configured separately for both
ports using the following parameters:
Parameter Index Subindex Value
Incre-
ments
Factory setting
Kp 15030 for X1.0
15031 for X1.1
1 0…2000000000 1 0
Ki 15030 for X1.0
15031 for X1.1
2
Kd 15030 for X1.0
15031 for X1.1
3
Tab.6: Parameter PWM-I PID for X1.x
The device can measure the generated current.
The value is read via [Process data in] (Ò IODD).
4.12.2 Configuration example
The following table contains examples of settings that can be used as a starting point for optimising
the PID controller (for a PWM-I frequency of 1000 Hz):
Connected load Kp Ki Kd
Resistor 24Ω 1 10000 0
Resistor 240Ω 1 100000 0
DC motor 10 W 1 500 0
Values outside the configuration can lead to an incorrect indication of a short-circuit.
4.13 SSC functionality
This function is only available in operating mode [Acyclic Enhanced].
The SSC functionality can be used in the following port modes and on the following pins:
• port mode 02; pin 2 of all ports (analogue input 4...20 mA)
• port mode 03; pin 2 of all ports (analogue input 0...20 mA)
• port mode 04; pin 2 of all ports (analogue input 0...10 V)
• port mode 05; pin 2 of all ports (analogue input 0...5 V)
• port mode 06; pin 4 of ports X1.2 and X1.3 (frequency input 0...3 kHz)
4.13.1 Configuration
The following IO-Link parameters can be configured separately for all 8 ports:
