AL1921 IO-Link master with EtherNet/IP interface
54
Available data points:
Name Description Value range Access
../counter Counter reading • 0…4294967295 rw
1
../interval Counting interval (value in ms) • 1000: 1000 ms
…
• 86400000: 86400000 ms
rw
1
../interval/unit Unit of the counting interval • ms: milliseconds ro
2
1
Read and write
2
Read only
9.2.16.1 Set the counting interval
Task: The counting interval of timer 2 is to be set to 2.5 s.
Solution: Using the setdata service to write the new value 2500 to the data point /timer[2]/
interval (2500ms = 2.5s).
Request:
{
"code": "request",
"cid": 1,
"adr": "/timer[2]/interval/setdata",
"data": {
"newvalue": 2500
}
}
Response:
{
"cid": 1,
"code": 200
}
9.2.17 IO-Link devices: Accessing parameters
The ifm IoT Core supports access to the parameters of connected IO-Link devices via the IT network
using ISDU (Index Service Data Unit). Each parameter can be addressed via its ISDU index and ISDU
subindex (Ò IODD of the IO-Link device). If access to the IO-Link device is faulty, the ISDU error code
will also be output in the response (Ò IODD of the IO-Link device).
Substructure: iolinkmaster/port[x]/iolinkdevice (x: 1…8)
Applicable services:
Name Description
../iolreadacyclic Read a parameter of an IO-Link device (acyclic)
../iolwriteacyclic Write a parameter of an IO-Link device (acyclic)
When using the validation level "Type compatible V1.1 Device with Backup + Restore":
After changing a parameter via ISDU write access, the user must end the parameter setting process
with the "ParamDownloadStore" system command and activate the data storage mechanism on the
IO-Link device.
u Set the SystemCommand object (ISDU index: 0x0002) to the value 0x05 (command
"ParamDownloadStore") via acyclic ISDU write access.
w The parameter setting process is finished.
