IO-Link master with EtherNet/IP interface AL1921
53
{
"code":"request",
"cid":10,
"adr":"iolinkmaster/port[2]/iolinkdevice/pdout/setdata",
"data":{
"newvalue":"01"
}
}
Response:
{
"cid":10,
"code":200
}
9.2.15 Ports: Reading port events
A port event contains information about events on the IO-Link port (e.g. IO-Link device connected or
disconnected, change of the operating mode of the port).
Substructure: iolinkmaster/port[x] (x: 1…8)
Available data points:
Name Description Value range Access
../portevent Port event
Structure: 0xYYZZ00
• 0xYY: Device Status - Status of
the IO-Link devices
• 0xZZ: Connection Status - Status
of the connection
Device status:
• 0x00: No IO-Link device connected
• 0x40: Wrong IO-Link device connected
• 0x80: IO-Link device connected and in
PREOPERATE state
• 0xFF: IO-Link device connected and in
OPERATE state
Connection Status:
• 0x00: Port deactivated
• 0x01: Port activated, but no device
connected
• 0x02: Port activated and in “IO-Link”
operating mode
• 0x03: Port activated and in “DI” operating
mode
• 0x04: Port activated and in “DO” operating
mode
• 0x1B: Repetitions detected
• 0x1E: Short circuit detected at pin 4
• 0x42: Wrong revision of the IO-Link device
• 0x43: Wrong vendor ID (V1.1 Revision)
• 0x44: Wrong device ID (V1.1 Revision)
• 0x45: Wrong vendor ID (V1.0 Revision)
• 0x46: Wrong device ID (V1.0 Revision)
• 0x48: Wrong cycle time
ro
1
1
Read only
9.2.16 Timer: Configuring the timers
The unit has 2 timers. The timers can be used for time-triggered transmission of notifications.
The timers are active by default.
Substructure: timer[1] | timer[2]
