AL1921 IO-Link master with EtherNet/IP interface
46
Name Description
../network/setblock Write all values of the substructure blockwise
u Change the parameters in the substructure network only block by block with the service
setblock!
9.2.9 Fieldbus: Setting the EtherNet/IP configuration mode
The device supports the EtherNet/IP configuration modes "Top-Down Mode" and "Independent Mode".
Substructure: fieldbussetup/configuration
Available data points:
Name Description Value range Access
../independentmode Configuration mode • 0: Independent mode off
• 1: Independent mode on
rw
1
2
../explicitmodepd Connection types (Input Assembly, Out-
put Assembly)
• 0: Explicit Process Data Mode off
• 1: Explicit Process Data Mode with
IO-Link I/O + Acyclic + Diag
• 2: Explicit Process Data Mode with
IO-Link I/O + Acyclic
• 3: Explicit Process Data Mode with
IO-Link I/O
rw
1
2
../processdataconfiguration Length of the process data • 0: 2 bytes input 2 bytes output
• 1: 4 bytes input 4 bytes output
• 2: 8 bytes input 8 bytes output
• 3: 16 bytes input 16 bytes output
• 4: 32 bytes input 32 bytes output
rw
1
2
../swap Swap of the bytes in process data • 0: Off
• 1: On
rw
1
2
1
Read and write
2
Read and write; parameter can only be changed if no active connection to fieldbus controller
9.2.10 Fieldbus: Setting fail-safe values of the outputs
If the EtherNet/IP connection is interrupted, fail-safe values can be set for the configured outputs of
the ports.
Substructure: fieldbussetup/configuration/port[x] (x:1…8)
Available data points:
Name Description Value range Access
../failsafedigitalout Fail-safe value for the digital output -
pin 4 (DO)
• 0: Failsafe – Reset value: default value
• 1: Failsafe – Old value: most recent
process value
• 2: Failsafe – Set value: HIGH level
rw
1
2
../failsafeiolink Fail-safe value for IO-Link output da-
ta - Pin 4 (IO-Link)
• 0: No failsafe: Fail-safe deactivated
• 1: Failsafe – Reset value: Fail-safe
activated – default value
• 2: Failsafe – Old value: Fail-safe – most
recent process value
• 3: Failsafe with Pattern: Fail-safe – byte
sequence
rw
1
2
1
Read and write
2
Read and write; parameter can only be changed if no active connection to fieldbus controller
