IO-Link master with EtherNet/IP interface AL1921
17
7.1.2 Ethernet
LED Description Colour State Description
LNK Status of the connection Green Off No Ethernet connection
On Ethernet connection established
ACT Status of the transmission Yellow Off No data transmission
Flashes Data transmission
7.1.3 Voltage supply
LED Description Colour State Description
PWR Status of the voltage supply Green Off no supply voltage is applied or the applied supply
voltage is too low
On Supply voltage US is connected
7.1.4 IoT
LED Description Colour State Description
LNK Status of the connection Green Off No Ethernet connection
On Ethernet connection established
IoT Device identification Green Flashes Device identification active
ACT Status of the data transmis-
sion
Yellow Off No data transmission
Flashes Data transmission
7.1.5 IO-Link ports (class A)
LED Description Colour State Description
Status of the IO-Link port
(pin 4)
Yellow Off Port mode DI / DO: Pin 4 (C/Q) = OFF
On Port mode DI / DO: Pin 4 (C/Q) = ON
Green Flashes (1Hz) Port mode IO-Link: No IO-Link device found
Flashes (5Hz) Port mode IO-Link: “PREOPERATE” state
On Port mode IO-Link: “OPERATE” state
Red Flashes (1.2Hz) IO-Link communication error
On Port configuration error or short circuit / overload
at US
DI Status of the digital input
(pin 2)
Yellow Off Digital input: Pin 2 = OFF
Flashes (5Hz) Digital input: Pin 2 = ON
