AL1591 SolutionBlock IO-Link master
38
Name Description Value range Access
[Bit rate] Transmission rate between the IO-Link
master and the IO-Link device
• COM1: 4.8kbaud
• COM2: (38.4 kbaud)
• COM3: 230.4kbaud
ro
1
1
Read only
2
Read and write; parameter can only be changed if no connection to fieldbus controller is established
Requirements:
ü ifm moneo|configure has been started.
ü The connection to the device is established (online).
ü Operating mode of pin 4 (US) of the port is IO-Link.
u Select the [Port x] > [IO-Link] menu (x = 1…8).
u Setting the cycle time
u Write the changed values to the device.
w The cycle time of the IO-Link port has been set.
9.1.5.5 Setting fail-safe values
When the EtherNet/IP fieldbus is enabled for configuration mode [Independent mode], the user can
set the fallback values for the port outputs. The fail-safe values will only be enabled if the EtherNet/IP
connection is interrupted.
Available parameters:
Parameter Description Value range Access
[Fail-safe digital out] Drop-out value for the output on pin 4
(C/Q) for "Digital output (DO)" operat-
ing mode
• Reset: LOW level (default)
• Old: Last active process value
• Set: HIGH level
rw
1
[Fail-safe IO-Link] Fall-back value of the output on pin 4
(C/Q) for "IO-Link" operating mode
• Off: Fail-safe disabled (default)
• Reset: Fail-safe enabled, reset process
value
• Old: Fail-safe enabled, last active process
value
• Pattern: Fail-safe enabled, byte sequence
rw
1
[Fail-safe DO/UA] Fall-back value of the output on pin 2
(I/Q) for "Digital output" operating
mode
2
• Reset: LOW level (default)
• Old: Last active process value
• Set: HIGH level
rw
1
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
2
Parameters only available for IO-Link ports (Class B)
Requirements:
ü The parameter setting software has been started.
ü The connection to the device is established (online).
ü EtherNet/IP field bus is enabled.
ü Configuration mode [Independent mode] is active.
u Select the [Port x] (x = 1…8) menu.
w The menu page shows the current settings.
u Setting fail-safe values
u Write the changed values to the device.
w Fail-safe values are configured.
