SolutionBlock IO-Link master AL1590
25
LED Description Colour Status Description
BF BF (Bus Failure): PROF-
INET status
red On PROFINET: bus error
SF SF (System Failure): sys-
tem status
-- Off System: error-free
red On System: error in the gateway or at least one IO-Link
port reports a warning/alarm (temperature, overcur-
rent, overvoltage, undervoltage, short circuit)
EtherNet/IP
LED Description Colour State Description
NET NET (Network Status): net-
work status
-- Off Not powered, no IP address: no voltage applied or
voltage applied but IP address not yet configured
Green/
red/ yel-
low
flashes quickly, al-
ternately
Self-test: Device in self-test after switching on
red /
green /
off
flashes, alternating Flashing sequence: Visual identification of the de-
vice
Green Flashes (1Hz) No connection: no CIP connection established and
no Exclusive Owner connection timeout
On Connected: At least one CIP connection estab-
lished and no timeout for Exclusive Owner connec-
tion
red flashes (1Hz) Connection Timeout: Timeout for Exclusive Owner
connection
On Duplicate IP: IP address used twice
MOD MOD (Module Status): Eth-
erNet/IP module status
-- Off No power: no voltage is applied or the applied volt-
age is too low
Green/
red/ yel-
low
flashes quickly, al-
ternately
Self-test: Device in self-test after switching on
red /
green /
off
flashes, alternating Flashing sequence: Visual identification of the de-
vice
Green Flashes (1Hz) Standby: device not yet configured (no IP address)
On Device operational: Device functions correctly
red flashes (1Hz) Major recoverable fault: serious, recoverable error
(e.g. incorrect configuration)
On Major unrecoverable fault: serious, unrecoverable
error (e.g. module failed)
7.2.2 Ethernet
LED Description Colour State Description
LINK Status of the connection -- Off No Ethernet connection
Green On Ethernet connection established
ACT Status of the data transmis-
sion
-- Off No data transmission
Yellow flashes Data transmission
7.2.3 Voltage supply
LED Description Colour State Description
US Status of the US supply
voltage
-- Off No supply voltage applied
