IO-Link master with EtherCAT interface AL1431
77
Mapping: Device status
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
n Error Code Port State
Legend:
• Port State Status of the IO-Link port 4 bit • 0x0: deactivated
• 0x1: Digital input
• 0x2: Digital output
• 0x3: IO-Link - OPERATE
• 0x4: IO-Link – STOP (error or no device)
• Error Code Error code of the IO-Link device
Note: If several errors occur at the
same time, only one error is dis-
played. The other error messages
are suppressed.
4 bit • 0x0: No error
• 0x1: Watchdog error
• 0x2: Buffer overflow
• 0x3: Invalid device ID
• 0x4: Invalid vendor ID
• 0x5: Invalid IO-Link revision
• 0x6: Invalid frame capability
• 0x7: Invalid cycle time
• 0x8: Invalid length of the input data (PD in)
• 0x9: Invalid length of the output data (PD out)
• 0xA: No device detected
• 0xB: PREOPERATIONAL error
• 0xC: Low voltage
• 0xD: Unspecified error
• 0xE: Short circuit
Mapping: Port Qualifier Information
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
n PVI DE DO DACT PVO res. DI2 DI4
Legend:
• DI4 Status digital input - pin 4 (operating
mode: DI)
1 bit • 0x0: LOW
• 0x1: HIGH
• DI2 Status digital input - pin 2 (if in use) 1 bit • 0x0: LOW
• 0x1: HIGH
• PVO Port Validity Output: Validity of the output
data of the IO-Link device
1 bit • 0x0: Invalid
• 0x1: Valid
• DACT Device deactivated: Shows if the IO-Link
port is configured and can be used
1 bit • 0x0: Activated and can be used
• 0x1: Deactivated or not available
• DO Device Operational: Availability of the IO-
Link device
1 bit • 0x0: Not available
• 0x1: Detected and in OPERATE state
• DE Device Error: Error or warning occurred;
Note: The user needs to determine the
cause of the error separately via acyclic
services
1 bit • 0x0: No error
• 0x1: Error (validation error, short circuit, etc.)
• PVI Port Validity Output: Validity of the input
data of the IO-Link device
1 bit • 0x0: Invalid
• 0x1: Valid
