AL1431 IO-Link master with EtherCAT interface
76
11.1.3.8 Device Area (0xF000 - 0xFFFF)
Index Subindex Name Possible values
Data type /
access
0xF000 Module Device Profile
• 0x01 Module Index Distance 0x0010 UINT16 / ro
• 0x02 Maximum Number of Modules 0x0004 UINT16 / ro
0xF100 Device status
• 0x01 Port 1: Device status
Mapping: Device status (Ò/77)
UINT8 / ro
• 0x02 Port 2: Device status
Mapping: Device status (Ò/77)
UINT8 / ro
• 0x03 Port 3: Device status
Mapping: Device status (Ò/77)
UINT8 / ro
• 0x04 Port 4: Device status
Mapping: Device status (Ò/77)
UINT8 / ro
0xF101 IO-Link Port Qualifier Information (PQI)
• 0x01 Port 1: PQI
Mapping: Port Qualifier Information (Ò/77)
UINT8 / ro
• 0x02 Port 2: PQI
Mapping: Port Qualifier Information (Ò/77)
UINT8 / ro
• 0x03 Port 3: PQI
Mapping: Port Qualifier Information (Ò/77)
UINT8 / ro
• 0x04 Port 4: PQI
Mapping: Port Qualifier Information (Ò/77)
UINT8 / ro
0xF102 Power Supply Status
• 0x01 Port Status UA/US
Mapping: Port Status UA/US (Ò/78)
UINT16 / ro
• 0x02 Global Status UA/US
Mapping: Global Status UA/US (Ò/78)
UINT16 / ro
• 0x03 Global Voltage UA (in mV) • 0x4E20: 20V
…
• 0x7530: 30V
UINT16 / ro
• 0x04 Global Current UA (in mA) • 0x0000: 0mA
…
• 0x1F40: 8000mA
UINT16 / ro
• 0x05 Global Voltage US (in mV) • 0x4E20: 20V
…
• 0x7530: 30V
UINT16 / ro
• 0x06 Global Current US (in mA) • 0x0000: 0mA
…
• 0x0E10: 3600mA
UINT16 / ro
0xF200 Pin 2 Digital Output Control
• 0x01 Digital Outputs (Pin 2)
Mapping: Pin 2 Digital Output Control (Ò/78)
UINT16 / rw
