IO-Link master with EtherCAT interface AL1431
67
11.1.3.2 Manufacturer-Specific Area (0x2000 - 0x5FFF)
Index Subindex Name Possible values
Data type /
access
0x2001 -- Component Name “EtherCAT IO-Link gateway” STRING / ro
0x2002 -- Vendor Name “ifm electronic” STRING / ro
0x2003 -- Vendor URL “www.ifm.com” STRING / ro
0x2004 -- Order Number "AL1431" STRING / ro
0x2005 -- Manufacturing Date STRING / ro
0x2006 -- QS Date STRING / ro
0x2007 -- Installation Location user-defined; max. 20 characters STRING / rw
0x200A -- Equipment ID user-defined; max. 20 characters STRING / rw
0x2F00 -- Reset to Factory • 0xA500: Factory Reset of System + NVMEM
• 0xA501: Factory Reset of System
UINT16 / wo
0x2F01 -- Device Localization • 0x00: LED blinking for 5s UINT8 / wo
0x2F02 -- Current Use Case • 0xA500: EtherCAT + IoT
• 0xA501: EtherCAT + IoT (read only)
• 0xA502: IoT (only)
UINT16 / rw
0x3100 Port 1: IO-Link Acyclic Command
• 0x01 Command Buffer
Mapping: Command Buffer (Ò/68)
ARRAY_OF_
BYTES / wo
• 0x02 Status • 0x00: Command completed: no error, no
response data
• 0x01: Command completed: no error, response
data available
• 0x02: Command completed: error, no response
data
• 0x03: Command completed: error, response
data available
• 0xFF: Command is executing (pending)
UINT16 / ro
• 0x03 Response Buffer
Mapping: Response Buffer (Ò/69)
ARRAY_OF_
BYTES / ro
0x3101
Port 2: IO-Link Acyclic Command (structure: Ò Index 0x3100)
0x3102
Port 3: IO-Link Acyclic Command (structure: Ò Index 0x3100)
0x3103
Port 4: IO-Link Acyclic Command (structure: Ò Index 0x3100)
