AL1431 IO-Link master with EtherCAT interface
66
Mapping: Flags
Word
(Offset)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n reserved OI MS DE DW DI EE
Legend:
• EE Enable Emergency sending (acc. to ETG.1000-6) 1 BIT • 0x0: Do not transmit diagnostic messages
as emergency messages
• 0x1: Transmit new diagnostic message
as emergency message
• DI Disable information messages 1 BIT • 0x0: Information messages are stored in
the message queue (default)
• 0x1: Information messages are not stored
in the message queue
• DW Disable warning messages 1 BIT • 0x0: Warning messages are stored in the
message queue (default)
• 0x1: Warning messages are not stored in
the message queue
• DE Disable error messages 1 bit • 0x0: Error messages are stored in the
message queue (default)
• 0x1: Error messages are not stored in the
message queue
• MS Mode selection 1 bit • 0x0: Override Mode
• 0x1: Acknowledge Mode
• OI Overwrite/discard information Override Mode:
• 0x0: no event
• 0x1: Unacknowledged messages were
overwritten (buffer overrun); Subindex
0x03 = 0
Acknowledge Mode:
• 0x0: no event
• 0x1: Buffer is full of unacknowledged
messages and new messages are
discarded
Mapping: Diagnosis Message
Parameter Description
• Value range
Data type /
access
Flags Event qualifier type • 0x0000: Notification
• 0x0001: Warning
• 0x0002: Error
UINT16 / ro
Text ID Text ID as reference to diagno-
sis text as defined in ESI file
• 0x0000: not Text ID
• 0x0001…0xFFFF: Text ID reference to ESI file
UINT16 / ro
Time Stamp Time Stamp (value in ms) 0x0000000000000000…0xFFFFFFFFFFFFFFFF UINT64 / to
Flags Parameter 1 Data type Parameter 1 • 0x0005: UINT8 UINT16 / ro
Parameter 1 IO-Link Port • 0x01: Port 1
• 0x02: Port 2
• 0x03: Port 3
• 0x04: Port 4
UINT8 / ro
Flags Parameter 2 Data type Parameter 2 • 0x0006: UINT16 UINT16 / ro
Parameter 2 Event Code
Depending on the device: Ò IODD description of
the IO-Link device
UINT16 / ro
Flags Parameter 3 Data type Parameter 3 • 0x0005: UINT8 UINT16 / ro
Parameter 3 Event Qualifier UINT8 / ro
