AL1431 IO-Link master with EtherCAT interface
54
Parameter Description Reference
Port Qualifier Information (PQI) Diagnostic information of the ports Device Area (0xF000 - 0xFFFF)
(Ò/76)
Port Status UA/US Status of the supply voltages UA/US at
the ports
Global Status UA/US Status of the supply voltages UA/US of
the device
Global Voltage UA Present voltage UA
Global Current UA Present current intensity UA
Global Voltage US Present voltage US
Global Current US Present current intensity US
9.3.9.1 TwinCAT-specific information
When the device is integrated into an EtherCAT project, TwinCAT automatically creates variable
nodes for diagnostic and status information in the Solution Explorer. The data is grouped in folders
under the device node.
Available objects:
Node group Node Description
TxPDO IO-Link Device Sta-
tus
• State of IO-Link Ch.1
• State of IO-Link Ch.2
…
• State of IO-Link Ch.4
Status of the IO-Link ports X1...X4
Device Area (0xF000 - 0xFFFF) (Ò/76)
TxPDO IO-Link Port Qualifi-
er
• Qualifier of IO-Link Ch.1
• Qualifier of IO-Link Ch.2
…
• Qualifier of IO-Link Ch.4
Port Qualifier Information (PQI) of the IO-Link port X1...X4
Device Area (0xF000 - 0xFFFF) (Ò/76)
TxPDO New Diagnosis
Message available
• New Message Available Flag Display of a new IO-Link event
Communication Area (0x1000 - 0x1FFF) (Ò/64)
TxPDO Timestamp • Timestamp timestamp
Communication Area (0x1000 - 0x1FFF) (Ò/64)
TxPDO Power Supply Sta-
tus
• Per port status UA/US
• Global status UA/US
• Global voltage UA
• Global current UA
• Global voltage US
• Global current US
Status of the voltages UA/US of the ports X1...X4
Status of the voltages UA/US of the device
Current values of the current intensities and voltages UA/
US of the device
Device Area (0xF000 - 0xFFFF) (Ò/76)
TxPDO Vendor Specific IO
Info Ch.1
• Current UA Ch.1
• Current US Ch.1
Current intensity of the voltages UA/US of port X1
Information Area (0x9000 - 0x9FFF) (Ò/74)
TxPDO Vendor Specific IO
Info Ch.2
• Current UA Ch.2
• Current US Ch.2
Current intensity of the voltages UA/US of port X2
Information Area (0x9000 - 0x9FFF) (Ò/74)
TxPDO Vendor Specific IO
Info Ch.3
• Current UA Ch.3
• Current US Ch.3
Current intensity of the voltages UA/US of port X3
Information Area (0x9000 - 0x9FFF) (Ò/74)
TxPDO Vendor Specific IO
Info Ch.4
• Current UA Ch.4
• Current US Ch.4
Current intensity of the voltages UA/US of port X4
Information Area (0x9000 - 0x9FFF) (Ò/74)
