IO-Link master with EtherCAT interface AL1431
53
Node group Variables Description
RxPDO Mapping of
Pin 2 Outputs
• Pin 2 Digital Output
Control
Digital output data of the port (pin 2)
9.3.8 Reading identification information
Identification information of the device is stored in the Communication Area (0x1000).
Access options:
• Using CANopen over EtherCAT (Ò/56)
Available information:
Parameter Description Reference
Device Type EtherCAT device profile Communication Area (0x1000 - 0x1FFF)
(Ò/64)
Manufacturer Device Name Device Name
Manufacturer Hardware Version Hardware version
Manufacturer Software Version Software version
Vendor ID Vendor identification
Product Code Article number
Revision Number Hardware version
Serial number Serial number
9.3.9 Reading diagnostic and status information
The diagnostic and status information of the IO-Link master and the connected IO-Link devices is
stored in different object areas.
Access options:
• Using CANopen over EtherCAT (Ò/56)
Available information:
Parameter Description Reference
Diagnosis History
Reading IO-Link events (Ò/55)
Communication Area (0x1000 - 0x1FFF)
(Ò/64)
Timestamp Operating time of the device (time
stamp)
Device ID Device ID of the IO-Link device Information Area (0x9000 - 0x9FFF)
(Ò/74)
Vendor ID Vendor ID of the IO-Link device
IO-Link revision IO-Link revision of the IO-Link device
Frame Capability
Cycle Time Cycle time
PD In Length Length of the cyclic input data
PD Out Length Length of the cyclic output data
Serial number IO-Link Device Serial number of the IO-Link device
Current UA (Pin 2/5) Present current intensity of the voltage
UA (pin 2/5)
Current US (Pin 1/3) Present current intensity of the voltage
US (pin 1/3)
IO-Link State State of the IO-Link Diagnosis Area (0xA000 - 0xAFFF)
(Ò/75)
Lost frames Number of lost frames
Device status Diagnostic information of the IO-Link de-
vice
Device Area (0xF000 - 0xFFFF)
(Ò/76)
