AL1431 IO-Link master with EtherCAT interface
50
9.3.5 Configuring the ports
The ports are configured via the Configuration Area (0x8000) object area.
Changes to the port configuration in online mode must be activated separately.
u Activate changes with the Reconfigure (0x80n8, subindex 0x02) parameter.
The device does not have a failsafe function for the outputs of the ports. If the EtherCAT
connection is interrupted, the last output values present are written and marked as invalid.
A separate configuration area is available for each port.
Available parameters:
Parameter Description Reference
Device ID Device ID validation Configuration Area (0x8000 - 0x8FFF)
(Ò/72)
Vendor ID Vendor ID validation
IO-Link revision IO-Link revision validation
Cycle Time Cycle time
Process Data In Length Length of the cyclic input data
Process Data Out Length Length of the cyclic output data
Master Control Operating mode (pin 4)
Validation ID Validation methods and data storage
settings
Reconfigure Activate changes
Byte Swap Set arrangement of the bytes in the pro-
cess data
Mode UA Operating mode (pin 2)
Current Limit UA Restriction of current UA
Current Limit US Restriction of current US
