IO-Link master with EtherCAT interface AL1431
49
9.3.3 Setting the startup parameters
In the factory settings, a set of preset parameters is defined as startup parameters. The parameters
are transmitted to the device and activated when the EtherCAT connection is established.
In addition, the following parameters with user-specific values can be activated as startup parameters
for each port of the device:
Parameter Description Reference
Process Data In Length Length of the cyclic input data
Startup parameters (Ò/59)
Process Data Out Length Length of the cyclic output data
Master Control Operating modes of the port
To set the startup parameters:
Requirements:
ü The TwinCAT project has been created.
ü The device is integrated into the project.
u In the [Solution Explorer]: Select the node of the device.
w The detail window shows device settings.
u Select the [Startup] tab.
w The detail window shows configuration options of the device.
u Configure the startup parameters.
u Save the project.
w The startup parameters are transmitted to the device and activated when an EtherCAT connection
is established the next time.
9.3.4 Configuring the IO-Link master
The IO-Link master is configured via the Manufacturer Specific Area (0x2000) object area.
Access options:
• Using CANopen over EtherCAT (Ò/56)
Available parameters:
Parameter Description Reference
Installation Location Installation location can be set by the
user
Manufacturer-Specific Area (0x2000 -
0x5FFF) (Ò/67)
Equipment ID Equipment ID can be set by the user
Reset to Factory Resetting the device
Device Localization Trigger the flashing of the status LEDs
Current Use case Access rights to the device
