IO-Link master with EtherCAT interface AL1431
43
Name Description Value range Access
[applicationspecifictag] Application-specific tag ***: *** (Default) rw
2
1
read only; Parameter only available if operating mode pin 4 (US) = IO-Link and IO-Link device is connected to port
2
Parameter only available if operating mode pin 4 (US) = IO-Link and IO-Link device is connected to the port
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [Iolinkmaster] > [port[x]] > [iolinkdevice] submenu (x: 1…4).
w The menu page shows information about the IO-Link device.
u Optional: Enter the application-specific tag.
u Click on to save the changes to the device.
9.2.4.6 Reading IO-Link events
The device supports IO-Link events. IO-Link events are event and error messages. IO-Link events can
be generated in the IO-Link master and in the connected IO-Link devices. IO-Link events generated in
the IO-Link devices are forwarded to the IO-Link master and stored there.
An IO-Link event message has the following structure:
Byte 0…1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Event Code Source Validity Type Mode Instance
Legend
• Instance IO-Link Event Qualifier: Trigger 1 byte • 0x00: unknown
• 0x01: PL (Physical Layer)
• 0x02: DL (Data Layer)
• 0x03: AL (Application Layer)
• 0x04: APPL (Application)
• Mode IO-Link Event Qualifier: Event trigger 1 byte • 0x40: One-time event or warning
(single shot)
• 0xC0: Error disappeared
• 0x80: Error appeared
• Type IO-Link Event Qualifier: Event category 1 byte • 0x10: Notification
• 0x20: Warning
• 0x30: Error
• Validity Validity of the process data 1 byte • 0x00: Valid
• 0x40: Invalid
• Source IO-Link Event Qualifier: Event source 1 byte • 0x00: IO-Link device
• 0xFF: IO-Link master
• Event Code IO-Link event code (bytes are swapped!) 2 bytes
Ò IO-Link specification
Available parameters:
Name Description Value range Access
[iolinkevent] IO-Link event See above ro
1
2
1
Read only
2
Parameter only available if operating mode pin 4 (US) = IO-Link and IO-Link device is connected to the port
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [Iolinkmaster] > [port[x]] > [iolinkdevice] submenu (x: 1…4).
