IO-Link master with EtherCAT interface AL1431
35
Parameter Description Value range Access
[fieldbusfirmware] Firmware of the fieldbus e.g., 4.7.0.3 (EtherCAT Slave) ro
2
1
Read and write
2
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [Fieldbussetup] submenu.
w The menu page shows the current settings.
u Set the parameters of the EtherCAT interface.
u Click on to save the changes to the device.
w The EtherCAT interface of the device has been configured.
9.2.3.4 Setting the interval of the timer
Available parameters:
Name Description Value range Access
[interval] Interval of the counter (value in ms) • 0: deactivated
• 500: 500ms
…
• 2147483647: 2147483647ms
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [Timer[n]] submenu (n: 1…2).
w The menu page shows the current settings.
u Set the parameters.
u Click on to save the changes to the device.
w The intervals of the counter have been set.
9.2.3.5 Setting the operating mode pin 4 (US)
Pin 4 of ports X1...X4 supports the following operating modes:
• Disabled: No data transmission at pin 4 (C/Q) of the port
• Digital input: Binary input signal at pin 4 (C/Q) of the port
• Digital output: Binary output signal at pin 4 (C/Q) of the port
• IO-Link: IO-Link data transmission via pin 4 (C/Q) of the port
The set operating mode must match the operating mode of the device connected to the port (sensor,
actuator, IO-Link device).
Available parameters:
Name Description Value range Access
[mode] Operating mode of pin 4 (US) of the port • disabled: Port disabled
• di: Digital input
• do: Digital output
• io-link: IO-Link data
rw
1
