AL1431 IO-Link master with EtherCAT interface
34
When setting the parameters of the access rights in the parameter setting software, observe the
following notes:
• If the access rights in the fieldbus projection software and in the IoT Core Visualizer are set to the
value fieldbus + iot, the parameter values set on the fieldbus side always apply.
• For exclusive access to the device via the IoT Core Visualizer, set the access rights to the value iot
only and set the access rights to Keep settings in the fieldbus projection software.
• If the access rights in the IoT Core Visualizer are set to the value fieldbus + iot (read only), the
access rights in the IoT Core Visualizer can no longer be changed. To regain write access with the
IoT Core Visualizer, set the access rights to the value fieldbus + iot in the fieldbus projection
software.
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [iotsetup] submenu.
9.2.3.2 Configuring the interface to the monitoring software
To enable transmission of the process data of the IO-Link master to the monitoring software (e.g. ifm
moneo suite), the interface must be configured accordingly.
Available parameters:
Name Description Value range Access
[smobip] IP address of the interface to the moni-
toring software
e.g., 255.255.255.255 (default) rw
1
[smobport] Port number of the interface to the
monitoring software
• 0: 0
…
• 35100: 35100 (default)
…
• 65535: 65535
rw
1
[smobinterval] Interval for data transmission to the
monitoring software
• disabled: No transmission (default)
• 500: 500ms
…
• 2147483647: 2147483647ms
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [iotsetup] submenu.
w The menu page shows the current settings.
u Set the parameters of the interface.
u Click on to save the changes to the device.
w Interface to the monitoring software has been set.
9.2.3.3 Configuring the EtherCAT interface
The EtherCAT interface is used to connect the device to the EtherCAT network.
Available parameters:
Parameter Description Value range Access
[hostname] EtherCAT hostname e.g., alxx3x rw
1
