AL1431 IO-Link master with EtherCAT interface
24
u Write the changed values to the device.
w Interface to the monitoring software has been set.
9.1.5 Fieldbus: Configuring the EtherCAT interface
The EtherCAT interface is used to connect the device to the EtherCAT network.
Available parameters:
Parameter Description Value range Access
Hostname EtherCAT hostname e.g., alxx3x rw
1
Fieldbus firmware Firmware of the fieldbus e.g., 4.7.0.3 (EtherCAT Slave) ro
2
1
Read and write
2
Read only
To configure the EtherCAT interface:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
ü The detailed view of the device is active.
u Select the [Fieldbus] menu.
w The menu page shows the current settings.
u Set the parameters of the EtherCAT interface.
u Save the changes on the device.
w The EtherCAT interface of the device has been configured.
9.1.6 Ports: Setting the operating mode pin 4 (US)
Pin 4 of ports X1...X4 supports the following operating modes:
• Disabled: No data transmission at pin 4 (C/Q) of the port
• Digital input: Binary input signal at pin 4 (C/Q) of the port
• Digital output: Binary output signal at pin 4 (C/Q) of the port
• IO-Link: IO-Link data transmission via pin 4 (C/Q) of the port
The set operating mode must match the operating mode of the device connected to the port (sensor,
actuator, IO-Link device).
Available parameters:
Name Description Value range Access
[Mode Pin4 US] Operating mode of pin 4 (US) of the
port
• Disabled: Port disabled
• DI: Digital input
• DO: Digital output
• IO-Link: IO-Link data
rw
1
[Cycle time actual] Current cycle time of the data trans-
mission between the port and the
IO-Link device (value in microsec-
onds)
• 0: Best possible cycle time
• 1: 1µs
…
• 132800: 132800 µs
ro
2
3
[Bitrate] Current transmission rate between
the port and the IO-Link device
• COM1: 4.8 kbaud
• COM2: 38.4 kbaud
• COM3: 230.4 kbaud
ro
2
3
1
Read and write
2
Read only
