IO-Link master with EtherCAT interface AL1431
21
9 Settings
9.1 Parameter setting software
9.1.1 Supported parameter setting software
The device can be configured with the following parameter setting software:
• ifm moneo|suite
• ifm moneo|configure SA
u Install the desired parameter setting software.
u Activate the licences required for operation.
w The installed parameter setting software can be used for parameter setting of the device.
9.1.2 Getting started
Parameter setting with ifm moneo and ifm IoT Core Visualizer is only possible if the Ethernet
over EtherCAT (EoE) protocol is activated and configured on the EtherCAT master and the
EtherCAT slave.
u Observe the notes: Using Ethernet over EtherCAT (EoE) (Ò/46)
Requirements:
ü ifm moneo has been installed correctly on the laptop / PC.
ü ifm moneo has been set up.
ü Ethernet over EtherCAT (EoE) has been activated and configured.
ü The device has a valid IP configuration.
ü The laptop / PC is connected directly or via a suitable network coupling element (e.g. switch) to a
EtherCAT port (XF1, XF2) of the device.
u Start ifm moneo.
w The user interface appears.
u Click on the [Configure devices] tile.
