IO-Link master with EtherCAT interface AL1431
19
LED Description Colour State Description
US Status of the supply voltage
US
Green On Supply voltage applied
UA Status of the supply voltage
UA
Green Off No supply voltage is applied or the applied voltage
is too low
On Supply voltage applied
7.1.3 IO-Link ports (class B)
LED Description Colour State Description
Status of the IO-Link port
(pin 4)
Yellow Off Port mode DI / DO: Pin 4 (C/Q) = OFF
On Port mode DI / DO: Pin 4 (C/Q) = ON
Green Flashes (1Hz) Port mode IO-Link: No IO-Link device found
Flashes (5Hz) Port mode IO-Link: “PREOPERATE” state
On Port mode IO-Link: “OPERATE” state
Red Flashes (1.2Hz) Port configuration error or short circuit / overload
at US
On Transmission error
UA/DO Status of the IO-Link port
(pin 2)
Yellow Off Digital input: Pin 2 (UA) = OFF
On Digital input: Pin 2 (UA) = ON
Green Off IO-Link type A supply: Pin 2 (UA) = OFF
On IO-Link type B supply: Pin 2 (UA) = ON (not
switchable)
Red On Error: Overcurrent or undervoltage
