AL1430 IO-Link master with EtherCAT interface
36
Name Description Value range Access
[mastercycletime_actual] Current cycle time of the data transmis-
sion between the port and the IO-Link
device (value in microseconds)
• 0: Best possible cycle time
• 1: 1µs
…
• 132800: 132800µs
ro
2
[comspeed] Current transmission rate between the
port and the IO-Link device
• com1 (4.8 kbaud): 4.8 kbaud
• com2 (38.4 kbaud): 38.4kbaud
• com3 (230.4 kbaud): 230.4kbaud
ro
2
1
Read and write
2
Read only
In the IO-Link operating mode, the following parameters can be set additionally:
Name Description Value range Access
[mastercycletime_preset] Cycle time of the data transmission be-
tween the port and the IO-Link device
(value in microseconds)
• 0: Best possible cycle time
• 1: 1µs
…
• 132800: 132800µs
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [Iolinkmaster] > [port[x]] submenu (x: 1…4).
w Set the operating mode pin 4 (US).
u Optional: Set the cycle time of the data transmission between the port and the IO-Link devices.
u Click on to save the changes to the device.
w Operating mode of pin 4 (US) of the port has been set.
9.2.3.6 Setting the operating mode pin 2 (UA)
Pin 2 of ports 1…4 supports the following operating modes:
• Off: Pin 2 is disconnected from the power supply; Port operates as IO-Link port class A
• On: Voltage UA is connected at pin 2; Port operates as IO-Link port class B
• Digital output (DO): A binary output signal is available at pin 2; Port operates as a digital switching
output
Available parameters:
Name Description Value range Access
[mode_ua] Operating mode of pin 2 of the port • off (io-link type a supply): IO-Link Port Class A
• on (io-link type b supply): IO-Link Port Class B
• digital output: Digital switching output
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [Iolinkmaster] > [port[x]] > [powercontrol] submenu (x: 1…4).
u Set the parameters.
u Click on to save the changes to the device.
w The operating mode of pin 2 (UA) has been set.
