Je bekijkt pagina 23 van 121
IO-Link master with EtherNet/IP interface AL1325
23
w The menu page shows the current settings.
u Disable the security mode
u Write the changed values to the device.
w Sicherheitsmodus ist deaktiviert.
9.1.7 Fieldbus: Configuring the EtherNet/IP interface
For communication with the Ethernet/IT network, the IP parameters of the Ethernet/IT interface must
be configured.
Available parameters:
Name Description Value range Access
DHCP Enable / disable the DHCP client of the
device
• Static IP: IP parameters are set by the
user
• DHCP: IP parameters are set by a
DHCP server in the network
• BOOTP: IP parameters are set via
Bootstrap Protocol (BOOTP)
rw
1
IP address IP address of the EtherNet/IP interface e.g. 192.168.82.100
192.168.1.250 (Default)
rw
1
Subnet mask Subnet mask of the EtherNet/IP net-
work
e.g. 255.255.0.0
255.255.255.0 (Default)
rw
1
Default gateway IP address IP address of the network gateway e.g. 192.168.82.1
0.0.0.0 (Default)
rw
1
Hostname EtherNet/IP name of the device (max.
240 characters)
e.g. iol12.plant1 rw
1
MAC address MAC address of the device's EtherNet/
IP interface
e.g. 00:02:01:0f:c8:8f ro
2
Fieldbus firmware Version of the fieldbus firmware e.g., ro
2
1
Read and write
2
Read only
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
ü The detailed view of the device is active.
w The menu page shows the current settings.
u Set the IP parameters of the EtherNet/IP interface.
u Save the changes on the device.
w IP settings of the interface are configured.
9.1.8 Fieldbus: Setting the EtherNet/IP configuration mode
The device supports the fieldbus configuration modes "top-down" and "independent". For the
configuration mode "Independent", the user can additionally select the connection type.
Available parameters:
Parameter Description Value range Access
Independent mode EtherNet/IP configuration mode • Independent mode off: Configuration
via fieldbus PLC
• Independent mode on: Configuration
via the device
rw
1
2
